DESCRIPTION -:

The apparatus consists of rectangular transparent flow section connecting two tanks, the section can be easily removed or connected to two tanks. It converges for a small length & spanerges for the remaining length. Flow can be controlled by a gate valve. Pizometers connected to flow section, make it possible to measure pressure heads & give visual observations of hydraulic gradient
Specifications :-

1) Tanks : 2 numbers of suitable size mounted on stand.
2) Flow channel of 90 cm length made out of perspex sheets.
3) Prizometer tubes equispaced at 5 cm
4) Measuring tank of 100 lit. cap.
5) Stop clock
6) Prizometer tubes equispaced at 5 cm
7) Measuring tank of 100 lit. cap.
8) Stop clock

RANGE OF EXPERIMENTS -:

1) Bernoulli?s theorem for the flow of real liquid can be verified.
2) Hydraulic grade line & the total energy line along the flow section can be plotted & can be studied.

SERVICE REQUIRED -:

1) Suitable water supply arrangement. 0.5 to 3 L.P.S.
2) Suitable drainage arrangement.
3) Floor Space : 3m x 1.5m

DESCRIPTION -:

The apparatus consists of rectangular transparent flow section connecting two tanks, the section can be easily removed or connected to two tanks. It converges for a small length & spanerges for the remaining length. Flow can be controlled by a gate valve. Pizometers connected to flow section, make it possible to measure pressure heads & give visual observations of hydraulic gradient.

SPECIFICATIONS

1) Tanks : 2 numbers of suitable size mounted on stand.
2) Flow channel of 90 cm length made out of perspex sheets.
3) Prizometer tubes equispaced at 5 cm.
4) Measuring tank of 100 lit. cap.
5) Stop clock.
6) Prizometer tubes equispaced at 5 cm.
7) Measuring tank of 100 lit. cap.
8) Stop clock.

RANGE OF EXPERIMENTS

1) Bernoulli?s theorem for the flow of real liquid can be verified.
2) Hydraulic grade line & the total energy line along the flow section can be plotted & can be studied.

SERVICE REQUIRED -:

1) Suitable water supply arrangement. 0.5 to 3 L.P.S.

2) Suitable drainage arrangement.

3) Floor Space : 3m x 1.5m.

DESCRIPTION :-

It is designed to study Coriollis Component of Acceleration of a slider crank mechanism. Here the mechanical slider system is replaced by a continuous stream of water flowing through a steadily rotating pair of tubes. These tubes can be rotated at various speeds by using a swinging field motor which also acts as dynamometer. A Perspex window on top of the tank gives clear view of the process and prevents splashing of the water over the side of the tank. The dynamometer continuously measures torque applied to the rotating tubes.
The Equipment is self contained, water recirculating, provided with its own speed control unit and separate water circulation pump.

SPECIFICATIONS :-

1)Main Tank : Fabricated out of fibber glass plastic sheet.
2) Rotating Arms : 9mm/6mm orifice dia, 300 mm long.
3) Rotameter : 300 to 3000 LPH
4) Electric Motor : D.C. Swinging field, 0.5 H.P. 50 RPM
5) Mono block Pump : Single phase, pump with Motor 2400 LPH discharge.
6) Control: Consisting of ?
(a) pump switch
(b) Variac Speed Control
(c) Speed Indicator
(d) Main Switch.
7) Rigid Support Structures .

RANGE OF EXPERIMENTATION :-

Coriollis Component of Acceleration can be detrmined at various speeds of rotation and water flow rates.

SERVICE REQUIRED

1) Single phase A.C. Electric Supply 230 V A.C. 50 Hz.
2) Floor Space : 1.5 m x 1.5 m.

DESCRIPTION :

The total set up comprises of Centrifugal fan which blows air through a square duct which consists of several sections as following.
(A) INITIAL CONDITIONING SECTION
This section comprises of a cooling coil circuit, heater section and steam humidification system. This section enables simulation of normal year round weather conditions to some extent in the confined space of the duct.
B) FIRST OBSERVATION SECTION
This section consists of flow stabilization zone and temperature measurement section. Here condition of simulated air coming out of the first conditioning section is observed and recorded.
C) SECOND CONDITIONING SECTION
This section incorporates cooling coil, heaters and humidifier tubes as in first conditioning section. The equipment incorporated in this section can be operated suitably to bring final air condition somewhere near comfort conditioning zone.
D) SECOND OBSERVATION SECTION
This section incorporates flow stabilization zone and measurement section where final condition of air is observed and recorded after conditioning the same in second conditioning section.

FEATURES :-

Air conditioning is simultaneous control of temperature, humidity, air motion and purity of the atmosphere in a confined space. Air conditioning Trainer facilitates study of such air conditioning process especially related to comfort conditions. Unique facility of simulation of summer and winter conditions in the duct is speciality of Air Conditioning Trainer.

SPECIFICATIONS

1. Duct Size : 250 mm x 250mm x 2m. long (approx.)
2. Blower Fan : Driven by 0.5 H.P. (Approx.) 3 phase motor. Air flow 0.28 m/Sec. With butterfly valve inlet to control air flow rate.
3. Digital Temperature Indicator :
0-2000 C with 10 C least count, multi channel.
4. Steam Generator : compact unit provided with 1.5 Kw. Heater for generating steam.
Connected to both sections by insulated piping through hand control valves.
5. First and Second conditioning sections comprises of following :
a) Electrical Heater : finned U Tube air heaters 0.5 Kw. Capacity.
b) Dimmerstat : 230 V.A.C. Single phase, 5-10 Amp. Capacity. Common for both sections with selector swithch.
c) Energy Meter : 230 V.A.C. Single phase 5-10 Amp. Capacity.
d) High pressure Gauge for R-12 Refrigerant.
e) Low Pressure Gauge for R-12 Refirigerant.
f) Refrigerant flow meter for R-12 Refrigerant.
g) Cooling Unit : Comprising of sealed compressor, air cooled condenser, expansion valve and cooling coil in duct.
Capacity : i) 1st section 2/3 Ton
ii) 2nd section 1/3 Ton
h) HP-LP Cut out of suitable range.
7. Control panel consisting of proper switches and valves.
8. Sturdy fabricated frame for housing the duct, instrumentation and controls.
9. Dry and wet bulb thermometers 2 sets.

RANGE OF EXPERIMENTS

1. To find out C.O.P. of refrigeration circuit used for air conditioning applications.
2. Flexibility provided in creating wide range of entry conditions apart from ambient enables
3. students to study the year-round air conditioning process easily.
4. A range of experiments can be carried out at various air flow rates

SERVICE REQUIRED

1. R-12 Refrigerant : Approx. 7 kg.
2. Electric Supply : 15 Amps. 230V. and 32 Amps 440 V.A.C. continuous supply.
3. Space 5m x 3m.

DESCRIPTION :-

This is a water re-circulation system consisting of a water sump tank, mono block pump, top tray with drain, discharge measurement tank, and a bye-pass arrangement for the mono block pump.

Specifications :-

Table size - 1200 x 1000 x 800 (approx.)

2) Water Tray - 1200 x 1000 (approx.)

3) Sump Tank - 150 Lit. (approx.)

4) Discharge Measurement Tank - 50 Lit. (Approx.)

5) Monoblock Pump - 1 Phase, 230 V AC

6) Necessary Piping arrangement with a bye pass arrangement.

This bench is useful to conduct experiment on various set ups. At a time however, only one experiment set up can be used on this bench.
