Process Control Equipments
4 Digit Timer
Range : 9999 sec/min.
Mode : Delay On / Delay Off
Size : 96x96 mm
6 Digit Event Counter
MODEL : 246
Range : 999999 COUNTS
Mode : Reset Push Button
Sensor Input : Photo, Inductive & Micro Switch
Available with battery backup
Size : 96 x 48 mm
AC Voltage / Current Controllers
MODEL : 8010
Range : Any Specified Voltage / Current
Set Point : Single
Accuracy : ?0.5% Supply : 110V AC, 220V AC or 12V DC
Signal Input : Direct or through CT
Display : 3? Digit LED
Size : 96x96mm
AC Voltage / Current Controllers
MODEL : 8020
Set Point : Dual
Size : 96x96mm
Amp Hour Meter
MODEL : 800AH
Range : Selectable/ Programmable
Set Point : Single
Mode : Indicates present AH Value, Ampere & Total AH
Accuracy : ?0.5%
Supply : 110V AC, 220V AC or 12V DC
Signal Input : Shunt of Rectifier or Battery
Display : 6 Digit LED with Memory backup
Size : 96x96mm
Auto Temperature Scanner
MODEL : 6308
Range : 0-199.9, 600,1200, 1600?C
Accuracy : ? 0.5 % F.S
Mode : Auto/ Manual Selectable
Input Power : 230 V or 110 V ? 10 % 50/60 Hzt 50 Hz
Size : 96?96 mm Facia, 91?91 mm Cutout
Automatic Tissue processor
Blind Timers
Range : 99 sec or 99 min.selectable
Mode : Delay On / Delay Off
Size : 96x48 mm
Blind Timers
Range : 999 sec or 999 min.selectable
Mode : Delay On / Delay Off
Size : 96x48 mm
Conductivity Transmitter
Blind Type : Wall / DIN Rail mounted
Output : 4 - 20 mA Non Isolated
Auto Temperature Compensation
Supply : 220 V AC
Contact Tachometer
Display : Red 7 Seg LED
Resolution : 1 RPM
Range : 0-9,999 RPM
Accuracy : +/- 1 RPM
Operating Voltage : 6 V DC
Battery Required : 4 Nos 1015 Type (Pen Torch Cells)
Frequency Standard : Quartz Crystal
Gating Period : 1 sec.
Memory : Actuated by Touch Switch.
Battery : Low Inidication Provided Auto Shut off facility built-in.
Accessories : Male Female Rubber Centres
Rubber Disc to measure Surface Speed directly. Weight : approx 300 grms
Data Logger
MODEL : 6424
Number of Channels: 08,12,16 & 24
Input : Thermocouples, RTD?s , mV or mA
Output : RS232
Digital Conductivity Controller
Display : 1999 Counts
Cell Constant : 0.1 and 1
Set Points : 2 High and Low
Transmission : Output 0 - 2.0 V DC
Range : 199.9 ?s, 1999 ?s, 19.99 ms,199.9 ms
Temperature Compensation : Automatic Using External PT-100 Sensor..
Size : 96x96 mm
Digital Conductivity Indicator
MODEL : 5500
Display : 3 ? Digit 13mm High, RED LED
Cell Factor : 1.0 & 0.1 Selectable.
Conductivity Range:
A)For Cell Factor 1.0
1) 199.9 ?s/cm
2) 1999 ?s/cm
3) 19.99 mS/cm
4) 199.9 mS/cm
B) For Cell Factor 0.1
1) 19.99 ?s/cm
2) 199.9 ?s/cm
3) 1999 ?s/cm
4) 19.99 mS/cm
TDS Range : 2000 ppm
Temperature Compensation : Automatic Using External PT-100 Sensor. Size : 96x96 mm
Digital Humidity / Temperature Controller / Logger with RS-232 Output PC Interface
MODEL : 7210L-RS232
Sensor : 2 x PT-100
Temperature Control Range : 0-65?C
Humidity Control Range : 0-100%
Least Count : 1% for RH & 0.1?C for Temperature
Accuracy : 2% for RH & 0.2 ?C for Temperature
Display : Direct from Micro Processor Self Internal Lookup Tables
Controls : By 10-Turn Hellical Potentiometer.
Control Output:
? Temperature : 2 Relays are provided. One operating 0.5?C above the Set Point for Cooling and the other Operating 0.5?C below the Set Point for Heating.
? Humidity : 2 Relays are provided. One operating 1% RH below the Set Point for Humidification and the other Operating 1% above the Set Point for De- Humidification
Power Supply : 230V AC ? 15%
Features :
- Software provided to log and plot temperature & humidity with respect to real time clock.
- This equipment can provide hardware control from its Relays and Software Logging on the PC.
Digital Humidity Controller
Sensor : 2 x PT-100
Temperature Control Range : 0-65?C
Humidity Control Range : 0-100%
Least Count : 1% for RH & 0.1?C for Temperature
Accuracy : 2% for RH & 0.2 ?C for Temperature
Display : Direct from Micro Processor Self Internal Lookup Tables
Controls : By 10-Turn Hellical Potentiometer.
Control Output:
? Temperature : 2 Relays are provided. One operating 0.5?C above the Set Point for Cooling and the other Operating 0.5?C below the Set Point for Heating.
? Humidity : 2 Relays are provided. One operating 1% RH below the Set Point for Humidification and the other Operating 1% above the Set Point for De- Humidification
Power Supply : 230V AC ? 15%
Digital Humidity Indicator
Sensor : 2 x PT-100
Temperature Control Range : 0-65?C
Humidity Control Range : 0-100%
Least Count : 1% for RH & 0.1?C for Temperature
Accuracy : 2% for RH & 0.2 ?C for Temperature
Display : Direct from Micro Processor Self Internal Lookup Tables
Controls : By 10-Turn Hellical Potentiometer.
Power Supply : 230V AC ? 15%
Digital pH Controller
Display : 3 1/2 Digit LCD 12.5 mm
Range : 0.00 - 14.00 pH
Auto Temp Compensation : 0 - 100 ?C With PT 100 Sensor
Set Limits : 2 High and Low
Alarm Limits : 2 High Hi and Low Lo
Transmitter : 4 - 20 mA Isolated
Accuracy : 0.5% ? 1 Digit
Input Impedence : > 10?? OHMS
Calibration : : pH 4 and pH7
Digital pH Controller
Display : 3 1/2 Digit LCD 12.5 mm
Range : 0.00 - 14.00 pH
Auto Temp Compensation : 0 - 100 ?C With PT 100 Sensor
Set Limits : 2 High and Low
Transmitter : 4 - 20 mA Isolated
Accuracy : 0.5% ? 1 Digit
Input Impedence : > 10?? OHMS
Calibration : : pH 4 and pH7
Digital pH Controller
Display : 3? Digit LCD 12.5 mm
Range : 0.00 - 14.00 pH
Auto Temp Compensation : 0-100?C with PT 100
Sensor
Set Limits : 0 - 14.00 pH
Alarm Limts : Band type Alarm equally above / below
set limit.
Accuracy : 0.5% ?1 Digit.
Input Impedence : > 10?? Ohms.
Relay Outputs : 110V/220V AC @ 5 Amp.
Transmitter Output : 4-20mA Isolated
Calibration : Standard pH 7.00, Slope pH 4.00
Supply : 110/220V AC ? 10% Size : 96mm x 96mm
Digital pH Indicator
Range : 0-14 pH With 4-20 mA Transmitter
Auto Temp Compensation : 0 - 100 ?C With PT 100
Sensor
Accuracy : 0.5% ? 1 Digit
Input Impedence : > 10?? OHMS
Calibration : : pH 4 and pH7
Digital Preset Counter
MODEL : 254
Range : 9999 COUNTS
Mode : Preset With Thumb Wheel Switches
Available with battery backup
Auto or Manual operation
Size : 96 x 96 mm , 72 x 72 mm
Digital Preset Counter
MODEL : 256
Range : 999999 COUNTS
Mode : Preset With Thumb Wheel Switches
Available with battery backup
Auto or Manual operation
Sensor Input : Photo, Inductive & Micro Switch
Size : 96 x 96 mm
Digital Tachometer (Contact / Non Contact) Two-In- One
MODEL : CT-500
Measurement:
A. Photo Tachometer
Range : 20 RPM to 75,000 RPM
Distance : Operation from 50 mm to 150mm using a photo-reflective tape
Light : RED visible LED light
B. Contact Tachometer
Range : : 20 RPM to 25,000 RPM The upper speed is limited by error caused by rubber roller slippage >
Battery : : 4x1.5 V Penlite cells
Accessories :
Carrying Case- 1 pc.
RPM Adapter (Cone) - 2 pc.
RPM Adapter (Conical) - 1 pc.
Surface Speed Wheel - 1 pc.
(10 cm Circumference)
Operation Manual - 1pc.
Reflecting Tape - 1m
1.5V x 4 Pencil Cells
Digital Temperature Controller
MODEL : 6215
Range : 199.9, 600 1200, 1600?C
Single Set Point, Single Relay
Accepts TC, RTD, mV or mA Inputs
Size : 96X96mm
Digital Temperature Dial Gauge
MODEL : 6001
Dial Gauge : 0-199.9?C For Pt 100 RTD, 0-300?C For J Type
Types : Vertical or Horizontal
Battery : Single 9V Battery
Housing : MS Powder Coated
Size : 96?96 mm
Digital Temperature Indicators
| MODEL : | 6100 |
| Range : | 199.9, 600, 1200 OR 1600? |
| Accuracy : | ? 0.5 % |
| Signal Input : | TC, RTD, mV OR mA |
| Input Supply : | 110 V AC, 220 V AC OR 12 V DC |
| Size : | 96 ? 96mm, 72 ? 72mm, 96 ? 48mm |
Dual Setting Digital Temperature Controller
MODEL : 6252
Range : 199.9, 600 1200, 1600?C
Setting by 2 Nos. of 10-Turn Helical Potentiometers.
2 Relays Output For Alarm and Switching
Accepts TC, RTD, mV or mA Inputs
Size : 96X96mm
Hand Held Portable Digital Temperature Indicator
MODEL : 6160
Range:199.9, 1200?C
Available with Surface, Immersion, Needle & Air Probe
Use 4x1.5V penlite cells
Humidity Transmitter
Type : Capacity
Range : 0-100%
Output : 4-20 mA
Manual Tissue processor
Microprocessor
Microprocessor Based Digital Tachometer
Display: 4 Digit LED
Input: 1 pulse per revolution
Range: 20 to 75000 RPM
Accuracy: 0.01 % F.S.
Power Supply: 220 V AC
Sensor: Photo or Inductive
Size : Panel Mounting 96x96mm
Microprocessor Programmable Counter
MODEL : 2500
Dual Set Point, Dual Relay,
Range : 999999 Counts
Resolution : 0.1, 0.01 or 0.001 Selectable.
Multiplication Factor : 0.001 to 999.999 Selectable.
Mode : Up / Down Counting
with batch counting & totaliser
Auto manual mode<
Bulit in Memory backup
Sensor Input : Photo, Inductive & Micro Switch
Size : 72 x 72 mm
Microprocessor Timer
Range : 999.9 sec, min or hrs Selectable
Mode : Delay On / Delay Off Selectable
Size : 96x96 mm
Minical Fixed Point Calibrator
Sources milli volts corresponding to important fixed points for J, K, R
& S Thermo Couples and Ohms for PT - 100. Works on built-in Ni-Cd
Chargeable Battery as well as on 220 V AC
Fixed Points :
J : 50, 100, 200, 400 DEG C
K : 100, 300, 500, 800, 1000 DEG C
R : 1000, 1200, 1400, 1600 DEG C
S : 1000, 1400, 1600 DEG C
PT - 100 : 0, 50, 100, 200 DEG C
Accuracy : 0.1 %
Long Term Drift : 0.05 % per Annum
Multi Channel Temprature Indicator
MODEL : 6106
Range : 199.9, 600, 1200 or 1600?C
Accuracy : 0.5%
Input : TC or RTD
No of Channel Available :6, 8, 10, 12
Size : 96x96mm or 96x192mm
Multi Range / Multi Function Timer
MODEL : 1052_2_DIGIT99SEC_MIN
Mode : Delay On or Delay Off User Selectable.
Range
Model 1052 : 9.9 sec, 99 sec, 9.9 min, 99 min selectable.
Model 1053 : 99.9 sec, 999 sec, 99.9 min, 999 min
selectable.
Size : Size 96x96 mm, 72x72 mm
Non Contact Tachometer
Display : 4 Digit LCD with Leading Zero Blanking.
Measurement :
Range : 20 RPM to 75,000 RPM (Resolution 1RPM upto 9,999 RPM)
Distance : Operating from 3 to 5 inch using a Photo-Reflective Sticker.
Light : Red Visible LED Light ( No Filament Bulb Used)
Power Supply : 4 Standard Pencil Cells.
Accuracy : 1 RPM ? 1 LSD Below 9,999 RPM &10 RPM ? 1 LSD Above 10,000 RPM
Operation Temperature : 0 - 50?C
Memory : Automatic when 'Measure' Button is Released
Sampling Time : 1 sec over 60 RPM
Circuit : Micro Controller Based LSI
Calibration : Referred to Quartz Crystal. Weight : approx. 300 grms
Size : 160 x 60 x 45 mm
pH Transmitter
Blind type Wall/ DIN Rail mounted
Output : 4 - 20 mA Non Isolated
pH Transmitter
MODEL : 1002A
Blind type Wall/DIN Rail mounted
Output : 4 - 20 mA Isolated
Photo Sensor (Inductive / Photo Switches)
MODEL : 8030
Available: in AC & DC
Types : Available Diffused, Retro - reflective,through Beam
Logic : Available PNP-NPN / NO-NC
Portable Battery Operated Calibrator mV Source/Measure Resolution 0.1mV
MODEL : 6050V
Display : 3 ? Digit Red LED 0.3 inch
Source : 199.9 mV
Measure : 199.9 mV
Accuracy : 0.1%
Adjust : mV by 10-Turn Hellical Pot.
Power : 4 Pencil Cells.
Features :
- Source as well as measure facility
- Battery Operated, easy to carry.
Portable Battery Operated Precision Calibrator mV Source/Measure Resolution 0.01mV
MODEL : 6060V
Display : 4 ? Digit Red LED 0.39 inch
Resoulution : .01 mV
Accuracy : 0.01%
Adjust : mV by 10-Turn Hellical Pot
Power : 4 Pencil Cells.
Features :
- Source as well as measure facility
- Battery Operated, easy to carry.
- High Accuracy.
Process Controller
MODEL : 6510
Range : Any Specified Engineering Unit
Set Point : Single
Accuracy : ?0.5%
Supply : 110V AC, 220V AC or 12V DC
Signal Input : mV, mA or Frequency
Display : 3? Digit LED Size : 96x96mm
Process Controller
MODEL : 6520
Set Point : Dual
Size : 96x96mm
Process Indicator
MODEL : 6500
Range : Any Specified Engineering Unit
Accuracy : ?0.5%
Supply : 110V AC, 220V AC or 12V DC Signal Input : mV, mA or Frequency
Display : 3? Digit LED
Size : 96x96mm, 72x72mm, 96x48mm
Repeat Cycle Timer
Range
Model 1072 : 99 sec or 99 min. selectable
Model 1073 : 999 sec or 999 min. selectable
Size : 96x96 mm
Thermocouple & RTD Assemblies
Available in sheath size of 3, 4.5, 5, 6, 8, 10, 12.5, 19, 22 and 25 mm OD pipe Sheath material : SS 304, 310, 316 or 446 Ceramic Thermocouples available in 610 and 710 Die cast aluminium heads with brass terminals Wire size of 16, 14, 12 or 10 SWG All types and sizes of process fittings available in MS, SS or Brass
Thermowells fabricated as per the coustomer's drawings and specifications. Flame proof thermocouples certified by D.G.M.S. L - Shaped thermocouples for Salt Bath Special thermocouples for plastic and rubber extrusion e.g bayonet, screw, bolt and washer types.
Thermocouple Wire and Thermocouple Instrument Cable
| No. | Size | Type of Cable |
| 01. | 3/22 | PVC/PVC |
| 02. | 3/22 | PVC/PVC Asbestos |
| 03. | 3/22 | PVC/PVC/ASB/GI |
| 04. | 3/22 | PVC/PVC/GI |
| 05. | 3/22 | PVC/ASB |
| 06. | 3/22 | FG/FG |
| 07. | 3/22 | FG/FG/SS |
| 08. | 3/22 | FG/FG/ASB |
| 09. | 3/22 | ASB/ASB |
| 10. | 3/22 | ASB/ASB |
| 11. | 1/26 | Teflon/Teflon |
| 12. | 7/36 | Teflon/Teflon/SS |
| 13. | 7/36 | Teflon/Teflon/FG |
| 14. | 7/36 | Teflon/Teflon/FG/SS |
| 15. | 7/36 | Teflon/Teflon/SPC/Teflon |
| 16. | 40/36 | Neoprene Rubber |
