Physics Equipment

TICKER TAPE TIMER, 12V AC

For timing motion in one dimension on a piece of paper in the form of dots spaced at equal interval of time, An electromagnet enclosed in a box operates on 1 2V AC through a pair of 4mm sockets. The screw shaped hammer on the armature mounted at the top of enclosure moves up/down with the changing polarity of electromagnet and leaves well defined dot on paper strip moving beneath carbon paper disc. Guides on top of enclosure assure smooth and straight movement of paper strip. Amplitude of vibration of hammer can be varied to get sharp dot and relative position of carbon discs with respect to paper tape adjustable for their optimum use. Includes a stand for mounting paper tape roll. Complete assembly mounted on a stable, non-skid base, Supplied complete with paper tape and carbon paper discs.

TICKER TAPE TIMER, 12V DC

operates on 12V DC Produces dots at 1/50 seconds intervals only. It has an electromagnet with spring-loaded armature. which vibrates above a support table.

TICKER TAPE TIMER, ECONOMICAL

Economical model of Ticker Tape Timer, incorporating a paper tape holder comprising metal bush pressing into the center of tape spool and a pair of card end cheeks. with complete assembly mounted on sheet metal base. Supplied without tape.

TICKER TAPE TIMER, PLASTIC BODY, 6V AC

Complete unit mounted in an unbreakable moulded ASS plastic enclosure. Operates at 6V AC and produces dots on the tape using a carbon paper disc at a frequency of 50Hz. 4mm sockets provided on one side for electrical connection. Supplied with carbon paper discs.

Timing Set

The Timing Set is an accessory pack for time measurements in dynamics experiments. The Timing Set is a complete solution for measuring time in dynamics experiments such as cart collisions and free fall. COMPONENTS : • Electronic Timer • Photogate (2x) • Power Supply 12 V DC 220 AC.

TORSION APPARATUS, HORIZONTAL

Searle's pattern. For investigating the torsional rigidity of rods of different materials and to demonstrate that the angle of twist of a given rod over a fixed length is proportional to the applied force. The apparatus consists of two parallel metal support rods with heavy cast metal legs at their either end. One of the legs has ball bearing mounted pulley wheel at its outer side with its spindle carrying split collet chuck for holding one end of test rod, while other end of the test rod supported through the clamping block on the other leg. When loaded with masses through the nylon cord wound on the pulley wheel, twisting couple if applied to the test rod. Two aluminium scales, graduated 30?; 0-30?x 1?, fixed on pillar supports are mounted on the metal support rods along its length. Also included are two pointers, which when clamped to the test rod along its length and adjacent to the scale, indicates the torsion produced in the rod at that point. Supplied complete with two test rods, one each of brass and steel, nylon cord and hook for carrying masses, but without masses.

TORSION APPARATUS, VERTICAL

Specially designed apparatus for investigation into the stress and strain accompanying the torsion i. e., torsion modulus of rigidity of the substance. The apparatus consists of a two long metal mounting rods located vertically on a T-shaped assembly and are jointed at the top through another square metal rod. Three adjustable angle measure attachments, graduated in degrees, are located vertically along the lengths of the rods for measuring degree of rotation of experimental rod under torsion at the desired positions. The bottom T-shaped assembly has a circular drum on to which is connected the weight pan on its either side through lightweight cord. The cord wound on the drum, with the weight pan suitably loaded, provides the necessary torque to the experimental rod. Chuck is provided at the top as well as bottom with tightening screws to firmly hold the experimental rod. Complete assembly mounted on a heavy cast metal tripod base with leveling screws. Includes two experimental rods - one each of brass and steel.

Torsion Balance

Static and dynamical measurement of the torsional modulus of a metal wire. Specifications : Size: 37 x 35 x 100 cm – Weight: approx. 2.5 kg. Static and ynamical measurement of the torsional modulus of a metal wire. COMPONENTS : • Torsion balance (with protractor and clamp) • Pan for weights • Reference index • Mass (10 g) (8x) • Balance Arm with nylon string and weights • Metal wire diam. 0,4 mm (length 40 cm) • Metal wire diam. 0,6 mm (length 40 cm) • Metal wire diam. 0,8 mm (length 40 cm). LAWS & PRINCIPLES INVESTIGATED : • Moment of inertia • Torsional modulus • Oscillation’s period • Moment of a force.

TRACK FDR DYNAMICS TRDLLEYS / CARTS

A polished wooden track, about 2m long, with smooth, flat surface for motion experiments using trolleys or carts. The track is easily inclinable and incorporates raised side rails along the length to prevent the accidental falling of carts/trolleys,

TRANSFORMER, MERCURY VAPOUR LAMP

Suitable for Mercury Vapour Lamp, SO watts. Operates on AC Mains, 220-240V, 50/60Hz.

TRANSFORMER, SODIUM VAPOUR LAMP

Grid leak type, for operating Sodium Vapour Lamps rated at 35watts. Operates on AC Mains, 220-240V, 50/60Hz

TRIODE VALVE ON BASE

For studying the characteristics of a triode valve and its practical applications.

TUNING FORK, ELECTRICALLY MAINTAINED

For producing vibrations in the stretched strings. Comprises a thick sturdy steel tuning fork with its stem held securely in cast metal clamp, which in turn is mounted on a sturdy, streamlined, heavy cast metal base with provision for horizontal or vertical use. An electromagnet operating on 6V is positioned between both the prongs and can slide along the prong's length for adjusting the amplitude of vibration of prongs. End of both the prongs have a stylus for frequency measurement and threaded arrangement for Melde's experiment.

TUNING FORK, SET OF 13

Best quality plain shanks, with chromatic scale frequencies from C1(256Hz) to C2(512Hz). Complete set of THIRTEEN Tuning Forks supplied in a polished wooden case.

TUNING FORK, STANDING

Lightweight tuning forks, capable of standing upright, with specially wide sound irradiating surface, useful for exciting oscillations for the Kundt's tube.

TUNING FORKS, SET OF 8, ALUMINIUM

Made of aluminium, anodized, best quality, set of 8 tuning forks with frequencies same as in TUNING FORKS, SET OF 8, STEEL i.e. frequencies (Hz) C1-(256), D-(288), E-(32O), F(341.3), G-(384), A-(426.6), B-(480), C2-(512).

TUNING FORKS, SET OF 8, STEEL

Best quality, plain shanks, with frequency clearly marked. Set consisting one each of diatonic scale frequencies (Hz) C1-(256), D-(288), E-(32O), F(341.3), G-(384), A-(426.6), B-(480), C2-(512). Complete set of 8 tuning forks, supplied in a case.

TUNING FORKS, STEEL

Plain shanks, best quality, chrome plated / blued steel. Available in frequencies (Hz) C1-(256), D-(288), E-(32O), F(341.3), G-(384), A-(426.6), B-(480), C2-(512).

TUNNING FORK ON RESONANCE BOX

For demonstrating the formation of basic major cord. Comprises four tuning forks mounted on a single wooden box in a line at the top and having frequencies (Hz) of C1(256), E(32O), G(384), C2(512). Supplied with hammer.

TWO WAY SWITCH

A two way toggle switch mounted on the plastic case provides connection between left and middle 4mm sockets or middle and right 4mm sockets. Useful for switching circuits

U TUBE MANOMETER

U-shaped glass tube mounted on wooden stand for use as a manometerwith a scale 0?50cm fixed between the two arms of tube for reading the level difference between both the arms.

U TUBE MANOMETER DELUXE

Comprises a transparent flexible plastic tubing, bent in the form of U, mounted in a sturdy metal section with 20-0-20 scale, graduated in millimeters, at the front. A clear front cover provides safety to the apparatus. One end of the tubing has a rubber tube connected through an adapter for attaching it to a fluid circuit. Provided with a ring at the top for hanging

U TUBE MANOMETER GLASS UNMOUNTED

U-shaped glass tube mounted on wooden stand for use as a manometerwith a scale 0?50cm fixed between the two arms of tube for reading the level difference between both the arms.

U-Shaped Electromagnet
